Simplex Armored Patch Cord 5m FC Connector 3.0mm Yellow LSZH Flame Resistant ODN B2ca
Simplex Armored Patch Cord 5m FC Connector 3.0mm Yellow LSZH Flame Resistant ODN B2ca
CPR Fiber Cable, Spiral Armored Fiber Patch Cord, Spiral Armored Fiber Patch Jumper, Spiral Armored Fiber Cable Assembly
Armored fiber optical cable are available assembled with different lengths and connector types (like LC, SC, ST, FC),
making them adaptable to different networking and communications equipment.
| Item | Simplex Armored patch cord |
| Fiber | G657A, OM1, OM2, OM3, OM4 |
| Cable Diameter | 3.0MM or 2.0 MM |
| Cable Jacket | LSZH |
| Length | 2M |
| Insert Loss | ＜ 0.30dB |
| Return Loss | ≥50dB (UPC), ≥60dB (APC), ≥25dB (MM) |
| Temperature | -40℃~80℃ |
| Cable Grade | IEC60332-1-2, Eca, Dca, Cca, OFCR, etc. Comply with ROHS |
| | |
Spiral (Helical) armored fiber optical cables are used in various industries and environments to prevent physical damage.
Here are some common applications.
Industrial environmenT
Spiral armored fiber cables are widely used in the industrial environment of cables exposed to high temperature, heavy machinery. Spiral armored fiber cables provide protection of mechanical damage, like wear,crush, and impact.
Outdoor equipment
Spiral armored fiber cables are suitable for outdoor use, because Spiral armored fiber cables are UV- resistance, and can take temperature fluctuations, then are often used for outdoor communication networks, industrial and infrastructure projects.
Telecommunication
Spiral armoured fiber optical cables protect fiber from physical damage, so they can be applied for telecommunications networks, like FTTA, FTTH, FTTB, FTTR, etc..
